TECHNICAL PARAMETERS

• container manufactured according to DIN 30 722.1
• feed hook, height – 1570 mm – diameter 50 mm – quality of the material S 355
• supporting frame – INP 180 – outer dimension 1065 mm – reinforced in the middle
• floor – metal sheet, th. 5 mm, quality of the material S 235 JR
• walls – metal sheet, th. 3 mm, quality of the material S 235 JR
• side wall reinforcements – distance 1000 mm
• 1x longitudinal reinforcement from height 2250 mm
• upper profile – square section
• connecting the wall to the floor – 90°
• two steel rollers with lubricators and bronze cases
• double-winged door with upper hooke type “S” – protection against unintentional opening
• primer 60 my – outside and inside of the container
• one-colour top coat synthetic varnish 40 my – only inside of the container, in RAL, according to the customer’s wishes
• load capacity 15,000 kg
• all materials used are certified
• volume:up to 40 m3
