TECHNICAL PARAMETERS

• container manufactured according to DIN 30 720
• floor – metal sheet, th. 5 mm or 6 mm, quality of the material S 235 JR
• walls – metal sheet, th. 4 mm or 3 mm, quality of the material S 235 JR
• tilting walls – metal sheet, th. 3 mm or 4 mm, quality of the material S 235 JR
• lifting lugs – distance 1100 mm
• one-side single hanger
• corner reinforcement
• net hooks
• stackable
• primer 60 my – outside and inside of the container
• one-colour top coat synthetic varnish 40 my – only inside of the container, in RAL, according to the customer’s wishes
• load capacity 10,000 kg
• all materials used are certified
• volume: up 3 m3 to 12 m3

on request:

• double-sided single hanger
• double-sided triple hanger + perforated strip for load safety
• floor holes
• internal reinforcement
• retroreflective chevron marking
• tightly welded with water test
